EIZO CS2731
MONITOR EIZO CS2731 DE 27 PULGADAS
| Cabinet Color | Black |
|---|---|
| Panel | |
| Type | IPS |
| Backlight | Wide-Gamut LED |
| Size | 27.0″ / 68.5 cm |
| Native Resolution | 2560 x 1440 (16:9 aspect ratio) |
| Viewable Image Size (H x V) | 596.7 x 335.6 mm |
| Pixel Pitch | 0.233 x 0.233 mm |
| Pixel Density | 109ppi |
| Grayscale Tones | DisplayPort, HDMI: 1,024 tones (a palette of 65 thousand tones) DVI: 256 tones (a palette of 65 thousand tones) |
| Display Colors | DisplayPort, HDMI: 1.07 billion from a palette of 278 trillion DVI: 16.77 million from a palette of 278 trillion |
| Viewing Angles (H / V, typical) | 178°, 178° |
| Brightness (typical) | 350 cd/m2 |
| Recommended Brightness for Calibration | 120 cd/m2 or less |
| Contrast Ratio (typical) | 1000:1 |
| Response Time (typical) | 10 ms (Gray-to-gray) |
| Wide Gamut Coverage (typical) | Adobe RGB: 99% |
| Video Signals | |
| Input Terminals | DVI-D 24 pin (with HDCP), DisplayPort (with HDCP), HDMI (with HDCP, Deep Color) |
| Digital Scanning Frequency (H / V) | DisplayPort, DVI: 26 – 89 kHz, 23 – 61 Hz (VGA Text: 69 – 71 Hz)
HDMI: 15 – 89 kHz, 23 – 61 Hz |
| USB | |
| Function | 2 ports for monitor control 3-port USB hub |
| Standard | USB 3.0 |
| Power | |
| Power Requirements | AC 100 – 240 V, 50 / 60 Hz |
| Maximum Power Consumption | 110 W |
| Typical Power Consumption | 44 W |
| Power Save Mode | Less than 0.6 W |
| Standby Mode | Less than 0.6 W |
| Power Management | Power Save (DisplayPort Version 1.2a, DVI DMPM) |
| Features & Functions | |
| Digital Uniformity Equalizer | Yes |
| Preset Modes | Color Mode (Custom, Adobe RGB, sRGB, Calibration) |
| OSD Languages | English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
| Others | Color Adjustment (Brightness, Temperature, Gamma, Color Gamut, Hue, Saturation, Clipping, Gain, Independent 6-Color Control, Reset), Picture Expansion (Auto, Full Screen, Aspect Ratio, Dot by Dot), Input Color Format, Input Range, Noise Reduction, Auto Iuput Detection, Menu Rotation, USB CHARGE Port, Power Save, Indicatior, Beep, Input Skip, Mode Skip, USB Selection, Signal Info, Monitor Info, Key Lock, DP Power Save, DUE Priority, Signal Format, Monitor Reset |
| Physical Specifications | |
| Dimensions (Landscape, W x H x D) | 638 x 404.1 – 559.1 x 245 mm |
| Dimensions (Portrait, W x H x D) | 378.2 x 649 – 689 x 245 mm |
| Dimensions (Without Stand, W x H x D) | 638 x 378.2 x 64 mm |
| Net Weight | 8.9 kg / 19.6 lbs |
| Net Weight (Without Stand) | 6.1 kg / 13.4 lbs |
| Height Adjustment Range | 155 mm |
| Tilt | 35° Up, 5° Down |
| Swivel | 344° |
| Pivot | 90° |
| Hole Spacing (VESA Standard) | 100 x 100 mm |
| Environmental Requirements | |
| Operating Temperature | 0 – 35 °C |
| Operating Humidity (R.H., non condensing) | 20 – 80 % |
| Certifications & Standards (Please contact EIZO for the latest information.) | CB, CE, TUV/GS, cTUVus, FCC-B, Canadian ICES-003-B, VCCI-B, TUV/Ergonomics, RCM, EAC, RoHS, WEEE |
| Supplied Accessories (May vary by country. Please contact EIZO for details.) | AC power cord, signal cables (DVI-D – DVI-D [dual link supported], Mini DisplayPort – DisplayPort), USB cable, setup guide, EIZO LCD Utility Disk (PDF user’s manual), quick reference, warranty card |
| Warranty | Five Years 2 5 |
| Dimension Drawing |
